产品详情：
旋耕机系列：Rotary tiller
1GQN系列旋耕机/旋耕灭茬机是与拖拉机三点悬挂连接配套，采作中间齿轮传动，通过拖拉机后输出PTO进行驱动刀片旋转工作，具有拖拉机轮迹全部覆盖,节省劳动力，土质细碎，综合成本低等特点。
1GQN series of rotary tiller is adopted middle gear transmission system, mounted with the tractorthough the 3 point suspension.Tractor’s wheel tracks are completely covered after tillage as the working width is much wider. The quality is reliable and the performance is well. This cultivatorcan be used on dry and paddy field. It can reduce the time, laboring, and cost, etc.
Advantages:
l This mounted rotary tiller covers the tractor wheel track perfectly.
l The rotary cultivator saves labor and reduces the cost.
l It is a tractor mounted rotary tiller for 18-80hp tractor.
l The blade is 65Mn steel .
型号Model | 单位Unit | 1GQN- | |||||||||
100 | 125 | 140 | 150 | 160 | 180 | 200 | 220 | 250 | 300 | ||
工作幅宽Working width | mm | 1000 | 1250 | 1400 | 1500 | 1600 | 1800 | 2000 | 2200 | 2500 | 3000 |
工作深度Working depth | mm | 120-180 | |||||||||
PTO转速 PTO Rotation speed | r/min | 540－720 | |||||||||
PTO花键 PTO shaft spline | 六键6 spline | ||||||||||
刀片数量No.of blades | 18 | 26 | 30 | 34 | 38 | 42 | 46 | 50 | 58 | 70 | |
刀片型号Type of blade | IT225 | IT245 | |||||||||
整机重量Total weight | kg | 190 | 200 | 210 | 220 | 240 | 370 | 400 | 420 | 470 | 500 |
配套动力Matched power | hp | 12 | 20 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 90 |
挂接方式linkage | I类三点悬挂Three-point suspension I type | II类三点悬挂 Three-point suspension II type | |||||||||
选装配置The items selectable | 可选配八键传动轴PTO transmission shaft in 8 spline
| ||||||||||
型号Model | 单位unit | SGTN- | |||||||||
120D | 125D | 140D | 150D | 160D | 180D | 200D | 220D | 250D | 300D | ||
工作幅宽Working width | mm | 1000 | 1250 | 1400 | 1500 | 1600 | 1800 | 2000 | 2200 | 2500 | 3000 |
工作深度Working depth | mm | 120-180 | |||||||||
输入轴转速Rotation speed of input shaft | r/min | 540－720 | |||||||||
PTO花键PTO shaft spline | 六键6 spline | ||||||||||
刀片数量No.of blades | 24 | 24 | 24 | 24 | 24 | 32 | 32 | 40 | 40 | 56 | |
刀片型号Type of blade | L-860 | ||||||||||
整机重量Total weight | kg | 200 | 210 | 220 | 230 | 252 | 380 | 410 | 435 | 480 | 520 |
配套动力Matched power | hp | 12 | 20 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 90 |
挂接方式linkage | I类三点悬挂Three-point suspension I type | II类三点悬挂Three-point suspension II type | |||||||||
产品实拍
售后服务
1).厂家生产全新产品，量大从优，放心选购。
2).按国家规定质保一年，在此期间，如因质量问题我司免费提供维修件，
如人为损坏等问题可有偿提供配件等。
禹城恒兴机械竭诚欢迎您的垂询、洽谈和考察！
购机须知
1：关于运费：机械设备属于贵重大件物品，快递费用比较高，所以一般采用物流货运方式。购买之前，您可 以电话直接联系我们咨询产品细节并向我们询问运费事宜。全国各地路途远近有所不同，因此运费相差也比较 大，物流运费预付和提付是一样的，运费我们尽量帮您做成提付，即您收到货直接付给物流就可以，我们不会多收您的运费
2：关于发货：买家付款3-7天内我们将安排发货，买家收到货以后（基本都是物流）请查看一下包装箱是否 完好，如有明显的压扁或拆卸过的痕迹，请立刻与卖家联系！
需要您提供开票资料。
|
